ARE BOLT Cylinder Lock for 1996-2016 Ford Super Duty 1996-2014 F-150

This sale is for one SINGLE OUT STYLE BOLT LOCK CYLINDER FOR 1996-2014 Ford F-150 trucks and 1996-2016 Ford Super Duty trucks. This style of lock was used on ARE DCU commercial truck caps. Please review the images of the lock cylinder and how it is secured to the handle body. For this to be the correct cylinder, your handle assembly needs to have all the components shown on the sample handle image like the lock cam, return spring and "L" bracket the return spring secures to. This key uses the truck's ignition key to "program" the lock cylinder. This requires inserting the truck's ignition key into the lock and rotating it firmly back and forth several times. It is imperative the key is fully inserted during this process and rotate the key until it comes to a solid stopped position, then reverse directions.

1- Chevy/GMC bolt cylinder

1- E-clip

1- Parts diagram

THESE HAVE BEEN DISCONTINUED BY ARE SO WHEN WE SELL OUT THERE WILL NOT BE A WAY TO GET ANYMORE.
